Restriction Orifice — Find Flow Rate: Tutorial

Overview

This tutorial walks through two complete calculations using the Restriction Orifice — Find Flow Rate calculator. You will calculate the flow through an existing restriction orifice — once for a liquid (water) and once for a compressible gas (air), including a choked flow condition.

The calculator solves the inverse sizing problem: the orifice geometry is fixed and the upstream/downstream pressures are known; the output is flow rate. The governing equation for the base case is:

q = Cd × A × sqrt(2 × ΔP / ρ)

For compressible flow, the expansibility factor ε is applied:

q = Cd × ε × A × sqrt(2 × ΔP / ρ₁)

where ρ₁ is the upstream density and ε ≤ 1 corrects for gas expansion across the orifice.

Scope: This tutorial covers the Find Flow calculator only. If you need to size an orifice for a target flow, use the Restriction Orifice — Find Orifice Size calculator instead.

What You Will Do

1. Enter identification data, fluid properties, and pipe/orifice geometry for a liquid case and run the calculation.
2. Interpret the liquid results: pressure drop, Reynolds number, mass flow, and volumetric flow.
3. Repeat the same geometry with a gas at conditions that produce choked flow.
4. Interpret the gas-specific outputs: beta ratio, expansibility factor, critical pressure ratio, and the choked flow indicator.
5. Export results to an ISA S20 spreadsheet or save the calculation to your account.

Calculator Layout

The page is organised into three sections — Identification Data, Fluid Data, and Pipe Data — followed by a Results panel.

Identification Data

These fields populate the downloadable ISA S20 report header. None affect the numerical result.

Fluid Data

State switching: When you select Gas, the Density field disables and Molecular Weight + Temperature enable. The calculator derives gas density via the ideal gas law: ρ = P × M / (R × T). Switching back to Liquid restores the Density field.

Pipe Data

The beta ratio β = d / D is computed internally and displayed in gas results.

Example 1 — Liquid: Water

Scenario

A 4-inch line has a restriction orifice with a 10.943 mm bore. Upstream pressure is 14 bar(a), downstream 12 bar(a). Confirm the flow rate at these conditions.

Fluid Data

Set State of Matter to Liquid first.

Use consistent pressure references for P1 and P2 — the calculator uses ΔP = P1 − P2, so the absolute/gauge offset cancels as long as both share the same reference.

Pipe Data

This gives β = 10.943 / 101.6 ≈ 0.1077.

Reading the Results

Common Results

Specific Results

Choked flow for liquids: No choked flow check is applied. Liquid choking (cavitation onset) is a separate phenomenon. If cavitation is a concern, verify that P2 is well above the fluid vapour pressure at operating temperature.

Unit switching: After the calculation runs you can change the result unit selector (e.g. bar → psi, kg/s → lb/h) without re-running — the calculator applies a client-side conversion from the stored base value.

Example 2 — Gas: Air at Choked Conditions

Scenario

Same orifice and pipe geometry, now carrying air. Upstream 14 bar(a), downstream 7 bar(a). The pressure ratio P2/P1 = 0.500 is below the critical pressure ratio for air (~0.528), so choked flow is expected.

Fluid Data

Set State of Matter to Gas.

The calculator derives upstream density:

ρ = 1,400,000 × 0.02897 / (8.314 × 298.15) ≈ 16.37 kg/m³

Pipe Data

Same as Example 1: D = 101.6 mm, d = 10.943 mm.

Reading the Results

Specific Results — Gas

How Choked Flow Detection Works

The critical pressure ratio for an ideal gas:

r_c = (2 / (γ + 1))^(γ / (γ − 1))

For air (γ = 1.4):

r_c = (2 / 2.4)^(1.4 / 0.4) = (0.8333)^3.5 ≈ 0.528

• P2 / P1 ≥ r_c → Not choked. Flow proportional to sqrt(ΔP).
• P2 / P1 < r_c → Choked. Velocity at the vena contracta is sonic. Further reduction of P2 does not increase mass flow.

Practical consequence: If the calculator returns Choked Flow = Yes, the displayed mass flow is the maximum achievable at those upstream conditions. To increase throughput you must raise P1 or enlarge the orifice bore.

γ dependency: The critical pressure ratio depends on γ = Cp/Cv. The calculator uses γ ≈ 1.4 (diatomic gases). For other gases, verify against the Heat Capacity Ratio of Common Fluids table.

How the Expansibility Factor Works

The expansibility factor ε corrects for the reduction in gas density as it accelerates and expands from P1 to P2. A common approximation for sharp-edged orifices:

ε = 1 − (0.41 + 0.35 × β⁴) × x / γ

where x = ΔP / P1.

• ε = 1 for incompressible fluids (liquids).
• ε < 1 for gases; decreases as x increases.
• At choked conditions the calculator caps flow at the sonic mass flux — ε is not extrapolated beyond its valid range.

For small pressure drops (x < 0.1) the correction is minor. At x = 0.5 as in Example 2, ignoring ε would significantly overestimate the flow. The calculator applies it automatically.

Liquid vs. Gas: Key Differences

High-pressure gases: The ideal gas law (Z = 1) is adequate for moderate pressures. For gases with significant non-ideal behaviour at high pressure, obtain the actual density from a real-gas equation of state and enter it manually by switching to Liquid mode.

Exporting and Saving Results

• Download: Exports inputs and results as an ISA S20-format spreadsheet. Available to all users.
• Save Calculation: Registered users can store the full calculation set to their account via My Calculations, allowing later retrieval and modification.

Related Tools

• Flow Rate Calculator — General-purpose flow rate calculation for a fluid in a pipe
• Orifice Plate Calculator — Find Orifice Size — Size a metering orifice plate for a target flow rate
• Restriction Orifice — Find Pressure Drop — Calculate the pressure drop across a known restriction orifice at a given flow
• Restriction Orifice — Find Orifice Size — Size a restriction orifice bore for a required pressure drop and flow
• Heat Capacity Ratio of Common Fluids — Reference table of γ values for gases and vapours
• Absolute Viscosity of Common Gases — Reference table of dynamic viscosity for common process gases

Information and Definitions

Used Equation

Dimensional Analysis

Beta Ratio The ratio of the orifice diameter to the pipe diameter, affecting flow restriction and pressure drop. It is essential in flow measurement, with specific ratios optimizing accuracy for different flow ranges.

Choked Flow Choked flow occurs when a gas flow reaches maximum velocity due to critical pressure conditions, limiting further flow increase. It is vital in gas transport systems to avoid system inefficiencies and ensure safe operation.

Common Results Refers to standard calculations and outputs in fluid mechanics, such as flow rate, pressure drop, and velocity, essential for analyzing system performance and determining if the design meets operational requirements.

Contraction Coefficient A factor representing the reduction in cross-sectional area in a flow contraction, influencing flow speed and pressure. It is used in flow calculations involving orifices and sudden changes in pipe diameter.

Critical Pressure Ratio The critical pressure ratio is the ratio of downstream to upstream pressure at which gas flow becomes choked, meaning maximum flow rate is reached. It is essential in designing nozzles and controlling flow in compressible fluid systems.

Density Density is the mass per unit volume of a fluid, typically measured in kg/m3. It impacts fluid behavior, such as buoyancy and pressure. High-density fluids exert greater pressure in systems, influencing design parameters in piping and fluid transport applications.

Dynamic Viscosity Dynamic viscosity is a measure of a fluid's resistance to shear or flow, measured in Pascal-seconds (Pa·s) or centipoise (cP). It affects how easily a fluid flows through pipes and around objects, influencing energy requirements in pumping systems.

Expansibility Factor A correction factor for compressible fluids, accounting for gas expansion in flow through orifices or nozzles. It affects accurate flow measurements and is particularly important in high-pressure gas systems.

Fluid Data Refers to essential information about a fluid, including properties like density, viscosity, and specific heat. This data is crucial for calculating flow rates, pressure drops, and heat transfer in systems.

Limits of Use Defines the operational boundaries, like maximum pressure or temperature, for a system. Staying within these limits ensures safe, efficient operation and protects equipment from damage or failure.

Mass Flow (kg/h) The amount of fluid mass passing through a point per hour. It is critical for measuring fluid transport, affecting system sizing, energy requirements, and overall efficiency in industrial processes.

Mass Flow (kg/s) Mass flow in kg/s indicates fluid mass per second, important for real-time flow control and energy calculations in fast-moving fluid systems, especially in high-demand applications like power generation.

Molecular Weight Molecular weight is the mass of a molecule of a substance, measured in atomic mass units (amu). In fluid mechanics, it helps calculate the density of gases and affects the fluid's compressibility and flow characteristics.

Operating Pressure The pressure at which a system operates, influencing fluid density and flow rate. Higher pressures increase fluid density in gases, affecting flow calculations and system integrity. Operating pressure is crucial for safety, efficiency, and equipment durability in fluid systems.

Operating Temperature The temperature at which a fluid operates within a system, influencing its viscosity, density, and flow behavior. Higher temperatures generally decrease fluid viscosity, affecting the resistance to flow.

Orifice Diameter The diameter of an orifice or opening in a pipe, often used for flow restriction or measurement. It restricts flow, creating a pressure difference used to calculate flow rate, with smaller diameters increasing pressure drop and reducing flow.

Pipe Data Refers to the dimensions, materials, and specifications of piping systems, affecting fluid dynamics, resistance, and capacity. Pipe data is essential for designing efficient fluid transport systems and calculating parameters like flow rate and pressure drop.

Pipe Diameter Inside diameter of the pipe. All process calculations are based on the volume of the pipe which is a function of its internal diameter. Larger diameters reduce friction and resistance, improving flow efficiency.

Pressure Downstream Fluid pressure after passing through the restriction orifice. It impacts flow rate and is essential for calculating pressure drops, energy losses, and flow efficiency within the piping system.

Pressure Drop Pressure drop is the reduction in fluid pressure as it flows through a system, caused by friction, restrictions, or changes in elevation. Across a restriction orifice it is the driving force for the flow and is determined by the difference between upstream and downstream pressures.

Pressure Drop Ratio The ratio of pressure drop across an element to the inlet pressure. It helps assess energy losses and efficiency in a system, with high ratios indicating significant pressure loss and potential flow restrictions.

Pressure Ratio The ratio of outlet pressure to inlet pressure, used to describe pressure changes across systems. It is crucial in analyzing compressible flows, particularly in gas systems, to determine flow characteristics and efficiency. For gases, it determines whether flow is choked.

Ratio of Specific Heats The ratio of specific heats (γ or kappa) is the ratio of a fluid's specific heat at constant pressure to its specific heat at constant volume. It affects compressible flow and is critical in calculations involving gases and thermodynamics.

Reynolds Flow Regime The classification of flow as laminar, transitional, or turbulent based on the Reynolds number. It affects flow behavior, pressure drop, and efficiency, guiding the design and operation of fluid systems.

Reynolds Number A dimensionless number indicating whether a fluid flow is laminar or turbulent, calculated from fluid velocity, density, viscosity, and characteristic length. It helps predict flow patterns and friction losses in pipes and channels.

Specific Results Refers to calculated values unique to a system's conditions, such as specific flow rates or pressure conditions, essential for verifying that the system operates within desired parameters for performance and safety.

State of Matter Defines the physical state of a substance: solid, liquid, or gas, determined by temperature and pressure. In fluid mechanics, the state of matter affects fluid flow, density, and viscosity. Gases are compressible; liquids are nearly incompressible.

Velocity in Pipe The speed of fluid movement through the pipe, influenced by pipe diameter and flow rate. It affects pressure drop, energy losses, and is crucial for sizing pipes to avoid excessive turbulence or friction.

Volumetric Flow The volume of fluid passing through a point per unit time, often in m3/h. It is used in pump sizing, system efficiency calculations, and to ensure fluid supply meets demand in various processes.
